Double Conical Tensile Structure
405 INR/Square Foot
Product Details:
- Insulation Optional, generally not provided
- Door Material Not Applicable (Usually Open Structure)
- Window Material Not Applicable (Usually Open Structure)
- Life Span 15-25 years (Membrane), 50+ years (Steel structure)
- Wall Materials Open Sides / Optional Glass or Polycarbonate Paneling
- Open Style Open/Free Entry
- Dimension (L*W*H) Customizable, Typical: 10m x 6m x 5m (LxWxH)
- Click to View more
X
Double Conical Tensile Structure Price And Quantity
- 500 Square Foot
- 300.00 - 550.00 INR/Square Foot
- 405 INR/Square Foot
Double Conical Tensile Structure Product Specifications
- White
- PVC panel
- Designed to withstand seismic zone conditions as per location
- Not Applicable (Usually Open Structure)
- Optional, generally not provided
- High-Tensile Fabric Membrane & Galvanized Steel Frame
- Outdoor Shelter, Walkway Cover, Canopy, Event Space
- Not Applicable (Usually Open Structure)
- 15-25 years (Membrane), 50+ years (Steel structure)
- Not Applicable / Optional: 6-10mm if paneling is used
- Bolted & Welded Joints (Steel Frame)
- Customizable, Typical: 10m x 6m x 5m (LxWxH)
- Open/Free Entry
- Open Sides / Optional Glass or Polycarbonate Paneling
- Lightweight, typically less than 40 kg/m2
- Designed for wind/snow loads (as per code)
- Concrete / Paver Block / Customized as required
- Designed as per standards, typically 3-5 kN/m2
- 100% Waterproof Membrane
- Hot Dip Galvanized / Powder Coated
- Side curtains, branding, heaters, and fans (optional)
- B1/M2 flame retardant (membrane meets safety standards)
- Yes, provision for integrated lighting available
- Double Conical (Dual Cone Peaks)
- UV Stabilized Membrane
- Up to 150 km/h or as per client site
- Integrated Rainwater outlets at corners and valleys
- Minimal, periodic cleaning recommended
- Quick Installation, approx. 5-10 days for typical size
Double Conical Tensile Structure Trade Information
- 5000 Square Foot Per Week
- 7-10 Days
- All India
Product Description
Double Conical Tensile Structure provides an aesthetic look and creates a large ambiance which can be covered with the minimum column. You can use the high center point design which creates the outdoors view eye-catching. Double Conical Tensile Structure is mostly used for roofs as per the requirements of our customers.
Product Specification
|
Thickness |
8mm |
|
Shape |
Conical |
|
Built Type |
Modular |
|
Usage/Application |
Shop |
|
Is It Waterproof |
Waterproof |
|
Pole Material |
Mild Steel |
|
Color |
White |
|
Material |
PVC (Base Material) |
Distinctive Double Conical Design
Stand out with a dual-peak architectural form that provides both aesthetic appeal and efficient structural integrity. The unique double conical shape not only enhances visual interest but also facilitates effective water drainage and optimal use of covered outdoor space.
Durability Meets Safety
Rugged materials and expert engineering make this structure built to last. With UV-stabilized, fire-resistant PVC membranes and a hot-dip galvanized or powder-coated steel frame, the structure resists corrosion, fire, and harsh exposure, ensuring occupants' safety and asset longevity.
Quick Installation and Low Maintenance
Fabrication and assembly are streamlined via pre-engineered, bolted, and welded connections, so typical installations complete in just 5 to 10 days. Minimal regular cleaning keeps the structure looking fresh. Maintenance is limited, making it cost-effective over its long lifespan.
Versatile Usage and Customization
From event venues to walkway covers and canopies, this solution adapts across commercial and public spaces. Choose integrated lighting, side curtains, branding, heaters, or fans as needed. Dimensions, flooring, and paneling are fully customizable to your project's requirements.
FAQ's of Double Conical Tensile Structure:
Q: How is the Double Conical Tensile Structure installed, and how long does it take?
A: The structure uses a modular system with bolted and welded steel frame joints, allowing for efficient assembly on-site. Installation typically takes 5-10 days for standard sizes, depending on site conditions and customization options.Q: What materials are used in the construction, and how do they contribute to durability?
A: The roof membrane is made from UV-stabilized, 100% waterproof, flame-retardant PVC, while the frame comprises hot-dip galvanized or powder-coated steel. These materials provide robust protection from weather, corrosion, fire, and UV degradation, resulting in a life span of 15-25 years for the membrane and 50+ years for the steel structure.Q: Where can the Double Conical Tensile Structure be used?
A: It is ideal for outdoor shelters, walkway covers, canopies, and event spaces. Its customizable design and rigorous structural standards allow installation in varied environments, including commercial complexes, public spaces, and venues across India.Q: What integrated features enhance usability and comfort?
A: The structure includes integrated rainwater drainage outlets, supports provisions for lighting, and offers optional accessories such as side curtains, heaters, branded elements, and fans. These enhance functionality and comfort for diverse applications.Q: How does the structure handle different environmental conditions like wind and earthquakes?
A: Engineered for safety, the structure withstands wind loads up to 150 km/h and is designed as per local seismic zone requirements, making it suitable for challenging environments and ensuring user and structural safety.Q: When is periodic maintenance needed, and what does it involve?
A: Minimal maintenance is required; periodic cleaning of the membrane and steel frame is recommended to maintain appearance and longevity. Inspections for fastener integrity and drainage clearance should be done annually.Q: What are the benefits and customization options for this structure?
A: The structure offers rapid installation, minimal upkeep, extensive durability, and customization in size, roof and flooring type, optional paneling, and accessory selection-delivering tailored solutions to fit diverse outdoor and commercial needs.Tell us about your requirement
